products details

Created with Pixso. Home Created with Pixso. Products Created with Pixso.
Galvanized Steel Sheet
Created with Pixso.

Hot Rolled Zinc Coated Galvanized Steel Plate SGCC SGCH G350 G450 G550 DX51D

Hot Rolled Zinc Coated Galvanized Steel Plate SGCC SGCH G350 G450 G550 DX51D

Brand Name: ASTM, JIS, GB, AISI, BS
Model Number: SGCC,SGCH,G350,G450,G550,DX51D,DX52D,DX53D
MOQ: 1 Ton
Price: US $419.0-720.0 / Ton
Payment Terms: L/C, T/T
Supply Ability: 40000 Tons/Year
Detail Information
Place of Origin:
China
Certification:
ISO, RoHS, IBR,CE,CR
Thickness:
0.12-3 Mm Or As Request
Width:
300-2000mm, According To Customer Requirements
Length:
1000-1500mm
Zinc Coating:
40- 600 GM/M2
Surface:
Regular Spangle, Minimum Spangle, Zero Spangle
Tolerance:
+/-1%
Technique:
Cold Rolled, Hot Rolled
Hardness:
Soft Hard(60),medium Hard(HRB60-85),full Hard(HRB85-95)
Packaging Details:
Standard Seaworthy Packings
Supply Ability:
40000 Tons/Year
Highlight:

SGCC Galvanized Steel Plate

,

Zinc Coated Galvanized Steel Plate

,

Hot Rolled Gi Steel Plate

Product Description

SGCC,SGCH,G350,G450,G550,DX51D Hot Rolled Galvanized Steel Plate Zinc Coated


Galvanized Steel Sheet/Plate
With zinc coating on the surface of base layer, galvanized sheet can isolate air and water, protect cathodic, prevent corrosion of the substrate, and extend the steel service life. It has various surfaces, zero spangle, small spangle, regular spangle, big sequins, etc., different patterns and colors can be customized according to customer's needs and requirements.

The galvanized sheet we produced has lots advantages, strong corrosion resistent, excellent formability, customization... we are sure that you can always select one type that meet you best.

Hot Rolled Zinc Coated Galvanized Steel Plate SGCC SGCH G350 G450 G550 DX51D 0

Product name
Galvanized sheet Steel Sheet
Width
500-1500mm
Thickness
0.12mm-4mm
Length
100mm to 12000mm or as customer's request
Standards
AISI ASTM JIS SUS DIN GB
Certifications
ISO 9001 SGS,BV
Packing
Industry standard packaging or according to client's requirement
Payment
T/T,L/C,Western Union,Paypal,Apple Pay,Google Pay,D/A,D/P,MoneyGram
Delivery time
3-7 days or up to order quantity
Price terms
FOB,CRF,CIF,EXW all acceptable
Loading port
any port in China
Packing
standard export packing (inside:water proof paper,outside:steel covered with strips and pallets)
Tolerance
Thickness: +/-0.02mm, Width:+/-2mm

Hot Rolled Zinc Coated Galvanized Steel Plate SGCC SGCH G350 G450 G550 DX51D 1

Processing


Winding → double unwinding → cutting head and tail → Welding → Alkali washing → primary scrubbing → Electrolytic cleaning → secondary scrubbing → hot water rinsing → hot air drying → Inlet looping → Continuous annealing → Hot dip galvanizing (ceramic zinc pot) → Air knife purging (introduced) → Air cooling after plating → water quenching → Flat machine (reserved) → stretching straightener → Passivation treatment (reserved for fingerprinting) → Outlet looping → oiling → cutting → Winding → Unwinding → weighing → packing.



Packing and delivery


1.Packing :3 layers of packaging, kraft paper inside, water plastic film in the middle, the outermost GI steel plate tied with

steel belt or as required.
2.Shipping port: Tianjin/Shanghai/Qingdao
3.Shipment:
a. Length: ≤6m, loaded in 20GP Container.
b. Length: ≤12m, loaded in 40GP Container.
Remark: Size of 20GP Container (inside :5898*2352*2393mm)
Size of 40GP Container (inside:12032*2352*2393mm)
Size of 40HQ Container (inside:12032*2352*2698mm)
4.Delivery time: Within 7-15 days, depending on the situation.

Hot Rolled Zinc Coated Galvanized Steel Plate SGCC SGCH G350 G450 G550 DX51D 2

Company file


Wuxi Xinyi Steel Co., Ltd. is a professional production of steel products, steel plate, steel coil, steel pipe, galvanized steel plate, galvanized steel coil, galvanized steel pipe and other products production enterprises, testing equipment is complete, strong technical force. There are many kinds of products, good quality, reasonable price, fashion design, widely used in machinery manufacturing, metallurgical minerals, building materials, ships, aircraft, automobiles and other industries. Our products are widely recognized and trusted by users to meet the changing economic and social needs.
The company covers an area of 20,000 square meters, with more than 100 employees and an annual revenue of 180 million US dollars. We are willing to accompany customers to grow together, welcome new and old customers from all walks of life to contact us, create future business relations, common success!



FAQ:


Q1. How long can make delivery?
A: For stock products,will make shipments in 2-5 days after receiving deposit or receiving T/T;
for products need new production for common materials,usually make shipments in 7-10 days;
for products need special and rare materials,usually need 15-20 days to make shipment.

Q2. Can you provide the samples?
A:Samples can be provided with samples' charge and courier fee by the buyer's side.

Q3: Can we visit your factory?
A: Warmly welcome. Once we have your schedule, we will arrange the professional sales team to follow
up your case.


Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive.
Airline and sea shipping also optional.
For mass products, ship freight is prefered.
Q5. Can you accept customize?
A: Yes. It can be customized as per the customers' request.
